Emptying Systems

Before a product can be filled, mixed or dispensed, it is often necessary to remove it from its original container. For ViscoTec, neither the size of the barrel nor its shape makes any difference here. We will make sure that you find just the right systems (barrel emptying system, barrel unloading, cans emptying, bucket emptying, cartridge discharge systems and many more) that are perfectly coordinated to your original pail and meet your exact requirements. For excellent emptying and supplying results.

Whether it’s a cartridge, tin, bucket or barrel: ViscoTec’s technology makes the emptying process easy. And with our accessories, barrel changes at viscosities of around 80,000 to 5,000,000 mPas are performed quickly, cleanly and in a way that is gentle on the product. Integrated into a dosing system, it is possible to not only empty containers but also to supply the application systems directly (filling fluids). And the residual quantity in your barrel is under 1% – guaranteed!

Systems for material emptying

Continuous and constant product emptying for seamless production without interruption.

  • Container volume: 310 ml – 1,500 l
  • Emptying capacity: individually customizable
  • Viscosities: up to 7,000,000 mPas

We would be delighted to find out which model best suits your production process.

Emptying Systems “Industrial”

ViscoMT-D

Emptying System ViscoMT-D

AutomotiveElectronicsE-MobilityGeneral IndustryPlasticsAerospace Renewable / New Energies3D printing Abrasive fluids And other branches - Get in contact!



  • Container sizes: from approx. 100 ml to 5 l
  • Viscosities: from approx. 80,000 – 1,000,000 mPas
  • Max. removal performance resp. speed: 136 ml/min* resp. 80 rpm*

Further information?
We look forward to hearing from you.

ViscoMT-XS

Emptying System ViscoMT-XS

AutomotiveElectronicsE-MobilityGeneral IndustryPlasticsAerospace Renewable / New Energies3D printing Abrasive fluids And other branches - Get in contact!



  • Container sizes: from approx. 5 l to 50 l
  • Viscosities: from approx. 80,000 – 2,000,000 mPas
  • Max. removal performance resp. speed: 810 ml/min* resp. 80 rpm*

Further information?
We look forward to hearing from you.

ViscoMT-L

Emptying System ViscoMT-L

AutomotiveElectronicsE-MobilityGeneral IndustryPlasticsAerospace Renewable / New Energies3D printing Abrasive fluids And other branches - Get in contact!



  • Container sizes: from approx. 50 l to 300 l
  • Viscosities: from approx. 80,000 – 2,000,000 mPas
  • Max. removal performance resp. speed: 600 ml/min* resp. 80 rpm*

Further information?
We look forward to hearing from you.

ViscoMT-XL

Emptying System ViscoMT-XL

AutomotiveElectronicsE-MobilityGeneral IndustryPlasticsAerospace Renewable / New Energies3D printing Abrasive fluids And other branches - Get in contact!



  • Container sizes: from 50 l
  • Viscosities: from approx. 80,000 – 2,000,000 mPas
  • Max. removal performance resp. speed: 9,8 l/min* resp. 80 rpm*

Further information?
We look forward to hearing from you.

ViscoMT-C

Emptying System ViscoMT-C

AutomotiveElectronicsE-MobilityGeneral IndustryPlasticsAerospace Renewable / New Energies3D printing Abrasive fluids And other branches - Get in contact!



  • Container sizes: 310 to 900 ml (euro cartridges & semco cartridges)

Further information?
We look forward to hearing from you.

Emptying Systems “Hygienic”

ViscoMT-XS

Hygienic Emptying System ViscoMT-XS

BiotechnologyCosmeticsFoodMedical Technology Pharmaceuticals Abrasive MaterialsAnd other branches - Get in contact!



  • Container sizes: from approx. 10 l to 50 l
  • Viscosities: up to 7,000,000 mPas
  • Flow rate: up to 2,5 l/min

Further information?
We look forward to hearing from you.

ViscoMT-XM

Hygienic Emptying System ViscoMT-XM

BiotechnologyCosmeticsFoodMedical Technology Pharmaceuticals Abrasive MaterialsAnd other branches - Get in contact!



  • Container sizes: from approx. 50 l to 200 l
  • Viscosities: up to 7,000,000 mPas
  • Flow rate: up to 90 l/min

Further information?
We look forward to hearing from you.

ViscoMT-XL

Hygienic Emptying System ViscoMT-XL

BiotechnologyCosmeticsFoodMedical Technology Pharmaceuticals Abrasive MaterialsAnd other branches - Get in contact!



  • Container sizes: from approx. 200 l to 1,500 l
  • Viscosities: up to 7,000,000 mPas
  • Flow rate: up to 150 l/min

Further information?
We look forward to hearing from you.

  • We advise you on the right system for your application.
